Titanium Socket Weld Fittings are high-performance forged components known for their exceptional strength-to-weight ratio, outstanding corrosion resistance, and excellent performance in extreme temperature and pressure environments. Titanium offers superior resistance to seawater, chlorides, and aggressive chemical media.
Titanium Socket Weld Fittings are precision-forged as per ASME standards and are widely used in compact, high-pressure piping systems where leak-proof and vibration-resistant joints are required.
Titanium Socket Weld Fittings are available in commercially pure and alloyed grades to suit different service conditions. The most commonly supplied grades include Titanium Grade 2 and Titanium Grade 5 (Ti-6Al-4V), offering an excellent balance of corrosion resistance, strength, and durability.
Titanium Socket Weld Fittings Manufacturer in India | Titanium Gr 2 & Gr 5 Supplier
Applications of Titanium Socket Weld Fittings
| ● Chemical Processing & Petrochemical Plants |
| ● Marine, Seawater & Desalination Systems |
| ● Heat Exchangers & Condensers |
| ● Aerospace & High-Performance Engineering |
| ● Power Generation & Offshore Platforms |
| ● Medical, Pharmaceutical & Clean Room Piping |
Specification Table of Titanium Socket Weld Fittings
| Standard | ASME B16.11, ASTM B381 |
|---|---|
| Size | 1/8″ NB to 4″ NB |
| Pressure Class | 3000#, 6000#, 9000# |
| Type | Socket Weld Elbow, Tee, Cross, Coupling, Half Coupling, Union, Cap |
| Manufacturing | Hot Forged / Machined |
| Surface Finish | Annealed, Pickled, Machined Finish |
Titanium Socket Weld Fitting Grades (Sub-Products)
| ● Titanium Grade 2 – Excellent corrosion resistance with moderate strength, widely used in chemical, marine, and desalination systems |
| ● Titanium Grade 5 (Ti-6Al-4V) – High strength alloy with excellent fatigue resistance, used in aerospace and high-pressure piping applications |
Mechanical Properties of Titanium Socket Weld Fittings (Typical)
| Grade | Yield Strength (MPa) | Tensile Strength (MPa) | Elongation % |
|---|---|---|---|
| Titanium Grade 2 | 275 | 345 | 20 |
| Titanium Grade 5 | 880 | 950 | 14 |
