Stainless Steel Outlets are forged branch connection fittings designed to provide a smooth and reliable outlet from a main pipe run. These fittings ensure excellent strength, leak-proof performance, and superior corrosion resistance in demanding service conditions.
Stainless Steel Outlets are widely used in high-pressure and high-temperature piping systems across industries such as oil & gas, petrochemicals, power plants, chemical processing, and refineries where safe branch connections are critical.
Stainless Steel Outlets are manufactured in a wide range of austenitic and duplex stainless steel grades to suit various operating environments. Commonly supplied grades include SS 304, SS 304L, SS 316, SS 316L, SS 321, SS 310 and SS 904L, offering excellent corrosion resistance and mechanical reliability.
Stainless Steel Outlet Manufacturer in India | Forged Outlet Supplier
Applications of Stainless Steel Outlets
| ● Oil & Gas Pipelines and Refineries |
| ● Chemical & Petrochemical Processing Plants |
| ● Power Generation and Thermal Plants |
| ● Offshore and Onshore Installations |
| ● Pressure Vessels and Piping Systems |
| ● Fertilizer, Pharmaceutical & Specialty Chemical Industries |
Specification Table of Stainless Steel Outlets
| Standard | ASTM A182, ASME B16.11, MSS SP-97 |
|---|---|
| Grades | SS 304, 304L, 316, 316L, 321, 310, 904L |
| Type | Weldolet, Sockolet, Threadolet, Nippolet, Latrolet |
| Size | ½″ to 24″ (Custom sizes available) |
| Pressure Class | 3000, 6000, 9000 |
| End Connection | Socket Weld / Threaded / Butt Weld |
Stainless Steel Outlet Grades (Sub-Products)
| ● SS 304 / 304L – General corrosion-resistant applications |
| ● SS 316 / 316L – Enhanced resistance to chlorides and chemicals |
| ● SS 321 – Suitable for elevated temperature services |
| ● SS 310 – Excellent oxidation resistance at high temperatures |
| ● SS 904L – Designed for severe corrosive environments |
Mechanical Properties of Stainless Steel Outlets (Typical)
| Grade | Yield Strength (MPa) | Tensile Strength (MPa) | Elongation % |
|---|---|---|---|
| SS 304 | 215 | 505 | 40 |
| SS 316 | 205 | 515 | 40 |
| SS 321 | 205 | 515 | 40 |
| SS 904L | 220 | 490 | 35 |
